momo3000 wrote: ↑
02 Jul 2020, 22:50
PIN Connection:
1-GND to GND
2-vcc to 3V3
3-aout to GPIO13

Just a hint from my experience. I couldn't get stable readings out of this sensor when using 3.3V. I had to use 5V supply. I adjusted the voltage devider on my ESP8266 accordingly.

mrwee

What if you remove sendtohhtp? Does the rebooting stop?

mrwee

You need to: 1) go here: https://github.com/letscontrolit/ESPEasy/releases 2) Select "Assets" on the most recent version (Right now it's "Release mega-20200426") 3) Download the .zip file 4) Extract the .zip file 5) I'd first flash a blank .bin file, to make sure everything is clean (4MB or 16MB dep...

mrwee

That possible. But even when sending one value every 30 minutes to both controller, it fails so it does not seem to be related to the queue filling up. So I agree that it sounds like a bug. I'll log it on github.

mrwee

Can seem to get either TaskValueSet + taskRun or TaskValueSetAndRun to work with two controllers. My setup: ESP_Easy: ESP_Easy_mega-20200426_normal_ESP8266_4M1M.bin on an original D1 mini Pro 2.0 Controllers: 2020-05-12_20-53-03.png Tasks 2020-05-12_20-49-04.png Test rule On mqtt3#Value1 do TaskValu...

mrwee

mrwee wrote: ↑
12 May 2020, 12:45
Ok. thanks. But I assume that since I cannot set the interval to 0 in the GUI, it will still publish by iself, or ?

Just answering myself: Not if I disable the Publish to controller

mrwee

Ok. thanks. But I assume that since I cannot set the interval to 0 in the GUI, it will still publish by iself, or ?

mrwee

Hmm. I'm setting the dummy variable in a rule, but I need to publish it's value only when changed to ThingSpeak on Controller 2. Already have MQTT on Controller 1. Can't seem to find an example of that

mrwee

I can see that the minimal interval is 1 sec. But how can I just publish the value when it's updated? I don't wan't it a fixed interval. Is this by design?

mrwee

20181204 is pretty old. Why not try the latest?
https://github.com/letscontrolit/ESPEasy/releases

mrwee

I'm feeing my ESP's with 12V, then bringing it down to 5V or 3.3V using something like: https://www.aliexpress.com/item/32862089104.html?spm=a2g0o.productlist.0.0.5e642083Sqgsz2&algo_pvid=fd44b1e5-97cc-4199-b5b8-996adbbd935e&algo_expid=fd44b1e5-97cc-4199-b5b8-996adbbd935e-36&btsid=0be374361587229362...

mrwee

Quite a project :D Have you considered products like Shelly switch/dimmer? You need to be careful mixing low voltage GPIO's with 110/230V. There are some strict rules when e.g. having mixed cables in the walls. Also it's true that ESP8266 doesn't consume much current, but if you have many on the sam...

mrwee

If you connected 5V to the programming pins, then it's dead

mrwee

Just on update on the original projekt: I've reverted to using solenoid vales in one central place, and only have soil sensors de-centrally.

mrwee

That's why I thought maybe using commercial available battery powered 433 MHz temperature sensors might be the answer. My experience with 433MHz is very poor coverage. E.g. with the receiver inside our house, I could not pick-up a Oregon 433MHz temperature sensor 10 meters away :o I'm only using Wi...

mrwee

You're very welcome to share your project here, but all the "internal" details are better kept safe within your own domain.

mrwee

Does anyone know of an easy solution to providing a 5V pulse from an ESP8266 either as + / - or - / + to a solenoid valve like this one? https://www.aliexpress.com/item/32812194299.html?spm=a2g0o.productlist.0.0.18c93fd8ip3mJm&algo_pvid=d19ca364-abc4-4733-b7b6-fa066501fd1d&algo_expid=d19ca364-abc4-4...

mrwee

Thanks Shardan for your extensive (and overwhelming) comments & observations. Very appreciated!

I'll implement your suggestions (plus add the Soil Moisture Sensors which I had forgot

), hope you have the time to review it again.

mrwee

Google can sometime be a pain in the ... I read that some make it work, some don't. So I'll keep to the 3.3V for DS18S20's. Attached is my design for the automatic watering. Suggestions / comments are very welcome :D I'm trying to prepare for expansion, hence the additional bus / connectors. Schemat...

mrwee

Which ESP board are you using?

The YX5300 needs it's own SD card. I had problems with certain models, so make sure that part works before you troubleshoot elsewhere.

mrwee

Got it! Thanks :) To be on the (future expansions) safe side, I'm considering powering the circuit with 12V (the solinoid valve runs on 12V), and having 5V and 3.3V step-downs, each capable of ~2A to supply e.g. D1 Mini pro, ADS1115, sensors/relays etc.. I've searched on Aliexpress for applicable re...

mrwee

@ThomasB: You seem to have a good insight into designing the electronics. If I power some DS18B20's with 5V, I assume that I also need a level converter for the GPIO?

mrwee

Thank you Thomas. I think I've got the circuit layed out as per your suggestions. Now I need to sleep on it, just in case new ideas come up

mrwee

Thanks for your reply ThomasB, 1) I did consult the pin mapping guide, but I lack a clear explanation of which "applications" are suitable for each GPIO. But your suggestion to use ADS1115 is the way to go, so I've added that. 2) For the voltage converter, I've chosen a BC547, again based on your in...

mrwee

Hi Guys, I've begun designing an automatic watering system for our garden, based on ESPEasy (of course :D :D ) The overall design will include: 1 x Wemos D1 Mini Pro 2.0 2 x https://www.alibaba.com/product-detail/HL-YFB10-Water-Flow-Sensor-Hall_60806958258.html Water Flow sensors for measuring consu...

mrwee

Update: re-flashed to mega-20200204 and moved to GPIO-14. Seems to work like a charm! Thanks for the hint

mrwee

Good input, thanks. Will try another GPIO. They should be the real thing, as they're bought from an official shop.

mrwee

I am also struggling with DS18x20 sensors. Setup: Official Wemos D1 Mini Pro 2.0 6 x DS18S20 on 1,2m twisted cable DS18S20 are connected to GPIO-16 Powering D1 Mini Pro via USB (Have also tried 5V) DS18S20 are 3,3V powered from the Mini Pro Resister for DS18S20 is 4,7K Mega 20191208, pre-built bin F...

mrwee

Seems like a clever tool. Will also test

mrwee

Does the cars already have a 230V heater installed?

mrwee

Ok, that really sounds like a brilliant solution and will clearly remove a lot of the burden from each device making room for lots of fun :D. It is also great that the future (easily) supports ESP82xxx and ESP32, that makes it much more versatile and ready when ESP32 "takes over". Really looking for...

mrwee

.....but I think by the end of next year we may have shifted focus to ESP32 as it does give a lot more resources. I understand that the possibilities in ESP32 is more fun, but considering the fact that most "Wi-Fi IoT" devices are based on ESP82xx, you vill be loosing out on a huge market potential...

mrwee

No, sorry. Misread your post. Will check with 20190928 not 20191028

.
It won't be until sometime this weekend, as I'm traveling the next couple of days.

mrwee

Just to be sure it is not your bug, or maybe one of mine. You could test with the build (or sources) of 20190928. I changed a lot last month regarding the rules and there have been some reports of rules misbehaving. That's the version I'm currently running on, with the 24 task modification. Serial ...

mrwee

Just enabled debug log, it does fire the rule but nothing actually get's published. Will dig deeper

mrwee

Spoke too soon. Doesn't seem like rules are working. On MQTT#Connected do Publish %sysname%/IP,%ip% Publish IP/%sysname%,%ip% timerSet,1,300 endon On Rules#Timer=1 do Publish %sysname%/IP,%ip% Publish %sysname%/Uptime,%c_m2dhm%(%uptime%) Publish IP/%sysname%,%ip% Publish Uptime/%sysname%,%c_m2dhm%(%...

mrwee

Brilliant! Tried it, and I got 24 x tasks. Have been looking for this change in ESPEasy for a long time. I got one compile warning: "WARNING: library LiquidCrystal_I2C claims to run on avr architecture(s) and may be incompatible with your current board which runs on esp8266 architecture(s)", but it ...

mrwee

Just a small comment. It's best practice NOT to have a leading '/' when using MQTT. It should be changed in the default settings of ESPEasy.

mrwee

Original Wemos?

mrwee

I do think it's better than an AC relay at least. Maybe a solidstate variant is a better choice. But yes, always take your precautions when working with mains, it can kill

mrwee

https://www.aliexpress.com/item/3282824 ... 4c4djFFY1n is much better than using a relay. I'm using it to detect 230V presence and it works fine.

mrwee

The green LED is physically connected together with the relay to GPIO12. So remove the LED or put something black over it.

mrwee

+1. Great work!

mrwee

Your rule is only needed if you wish to switch the relay by button or other means. My examples take the published status coming from ESP Easy and updates your switch according to the status. If you enable "Interval" under the relevant device on ESP Easy and set it to e.g. 10 seconds, it will publish...

mrwee

This is one of my switches, using the new format: things file Thing topic TestLight "TestLight" @ "Test devices" { Channels: Type switch : command "Power Switch" [ commandTopic="TestLight/gpio/12", stateTopic="TestLight/Relay/Switch", on="1", off="0", autoupdate="false" ] } items file Switch TestLig...

mrwee

Use my example for switching on / off + getting status back from the device. The new MQTT binding (https://www.openhab.org/blog/2018-12-16-mqtt-arrives-in-the-modern-openhab-2-x-architecture.html) in openHAB brings the possibility of auto-discovery, increased stability and many other things. But for...

mrwee

Just took a look at my old 1.x MQTT config in OH, and these were my settings for an Sonoff Basic with ESPEasy: device.items Switch Nano "Nano" <light> [ "Lighting" ] {mqtt=">[mosquitto:Nano/gpio/12:command:ON:1.00],>[mosquitto:Nano/gpio/12:command:OFF:0.00],<[mosquitto:Nano/gpio/12:state:MAP(onoff.m...

mrwee

Which openhab version are you on?

Also note, that it's against best practice to have a leading '/' in the subscribe/publish settings. It still works, if configured correctly it's just best to avoid

mrwee

@grovkillen: I think you need to do more advertising / publishing news on the development status, if you wish to get more people to contribute. It feel pretty quiet considering you're in need of funding. I'm sure there's many people out there (including myself) who would love to see ESPeasy suceed, ...

mrwee

Personally I'm fine with people selling stuff here, but it would be a good idea with a sub-forum.
